Welcome to the Virtual Project update for the I-10 Project Development and Environment (PD&E) Study
- Use a modern browser for enhanced user experience. (Safari, Chrome, Edge, Firefox)
- Please use your keyboard arrows or click the arrows on the left and right sides of the screen to navigate through this material. To enlarge a graphic simply click on the graphic to magnify.
- To provide a comment at any point during your visit, click on the “Comment” button at the bottom of your screen.
- Click below for the Project Handout.

Project Location Map
The FDOT is conducting a Project Development and Environment (PD&E) Study to consider capacity improvements along SR 8 (I-10) from east of SR 261 (Capital Circle) to west of SR 59 (Gamble Road), a distance of approximately 13 miles. These capacity improvements consist of widening I-10 from four to six lanes in eastern Leon County and western Jefferson County. Interchange improvements will also be considered at SR 261 and US 90 (Mahan Drive).

Roadway Typical Sections
A typical section is a visual representation of the existing roadway elements as they currently are today or a visual representation of what the new roadway elements will be after the improvements. The existing I-10 roadway consists of two 12-foot travel lanes in each direction divided by a 64-foot median with paved shoulders. The proposed typical section includes three 12-foot travel lanes in each direction. The opposing travel lanes are separated by a 40-foot grassed median that includes 10-foot shoulders and a traffic barrier.

Bridge Typical Sections
Similar to the roadway typical sections, the bridge typical section is a visual representation of the existing or proposed roadway elements. The existing bridges typical section consists of two 12-foot travel lanes in each direction with paved shoulders. The proposed typical section includes three 12-foot travel lanes in each direction with paved shoulders. The opposing travel lanes are separated by a traffic barrier.

Concept Plans
Click on the portion of the map below to zoom to the plan with the detailed improvements shown
Interactive Map
You can left click then drag the map to change the area you are looking at and use the +/- signs in the corner to zoom. Please click the arrow in the upper left corner to view the legend.
Evaluation Matrix
As a part of the PD&E process, the Build Alternative has been developed and evaluated for potential environmental impacts, as well as its satisfaction of the project’s Purpose and Need. This Evaluation Matrix summarizes the potential benefits and impacts to widening I-10 between SR 261 (Capital Circle NE) and SR 59 (Gamble Road). As the proposed option continues to be refined, impacts to social, environmental, cultural, and physical resources will be avoided and minimized to the extent practicable.

Contact Information
Website
Documents
Other Projects
Contact Us:
Sherry Alaghemand, P.E.
FDOT Project Manager
(888) 638-0250, extension 1510
sherry.alaghemand@dot.state.fl.us
Ian Satter
FDOT District Three Public Information Director
(888) 638-0250, extension 1205
ian.satter@dot.state.fl.us
Please Mail Comments to:
FDOT District 3
Sherry Alaghemand
1074 Highway 90
Chipley, Florida 32428
